Trigger input/output IDs

Constants and Macros used to identify device trigger inputs and device trigger outputs in individual instruments and combined instruments. More...

Collaboration diagram for Trigger input/output IDs:

Modules
	Device Numbers
	Device numbers used to determine the correct device in a combined instrument, to select a device trigger from.
	Port Group IDs
	IDs used to identify the origin for a device trigger.
	Device Sub Group IDs
	Function IDs
	Shift constants
	Bit shift contacts, used to determine trigger input anf output IDs.
	Trigger input IDs
	Trigger Input IDs, for individual instruments.
	Trigger output IDs
	Trigger Output IDs, for individual instruments.

Detailed Description

Constants and Macros used to identify device trigger inputs and device trigger outputs in individual instruments and combined instruments.
